HD-ready innovative teaching solution with a large scalable screen size of up to 100 inches, designed to enhance collaborative learning.
High brightness and image quality
Epson’s 3LCD technology ensures high-quality images with equally high White and Colour Light Output for vivid colours and bright images, even in daylight, and three times brighter colours than leading competitive projectors. With a scalable display size of up to 100 inches, two types of content can be displayed using the split-screen without compromising on quality.
Finger-touch and dual pen
Use your fingers to annotate directly onto the screen. Epson’s interactive pens are now even more responsive and easy to use. With the new dual pens, teacher and student or two students can work simultaneously using different attributes.
Highly reliable
Project for longer with improved reliability and a longer lamp life of up to 10,000 hours in eco mode.
Interact and enhance learning
Multi-PC projection software allows teachers and students to share content simultaneously. The moderator function allows teachers to remain in control, choosing what content to display. Combine two projectors to create one large interactive display. Split-screen capability allows teachers to display two separate types of content simultaneously, such as a lesson plan from a PC and a still image or video clip from a document camera.
Optional wireless capability
Wirelessly display content easily from a range of smart devices and Google Chromebooks using our iProjection App.
Key Features
- Up to 100-inch display and outstanding quality HD-ready WXGA resolution with Epson 3LCD technology
- Finger-touch and dual pen Use your fingers to annotate directly onto the screen
- Highly Reliable Improved reliability and a longer lamp life
- Multi-screen interactivity Combine two projectors to create one large interactive display
- Wireless Connectivity (Optional) Allows content to be shown from a range of devices
Technical Specification:
Technology:
- Projection System: 3LCD Technology
- LCD Panel: 0.59 inch with D9
Image:
- Color Light Output: 3,500 Lumen- 2,900 Lumen (economy) In accordance with IDMS15.4
- White Light Output: 3,500 Lumen – 2,900 Lumen (economy) In accordance with ISO 21118:2020
- Resolution: WXGA 2
- High Definition: HD ready
- Aspect Ratio: 16:10
- Contrast Ratio: 14,000: 1
- Light source: Lamp
- Lamp: 250 W, 5,000 h durability, 10,000 h durability (economy mode), 9,000 h durability (economy mode)
- Keystone Correction: Manual vertical: ± 3 °, Manual horizontal ± 3 °
- Colour Video Processing: 10 Bits
- 2D Vertical Refresh Rate: 100 Hz – 120 Hz
- Colour Reproduction: Upto 1.07 billion colours
Optical:
- Throw Ratio: 0.28 – 0.37:1
- Zoom: Digital, Factor: 1 – 1.35
- Lens: Optical
- Screen Size: 60 inches – 100 inches
- Projection Distance Wide: 0.4 m ( 60 inch screen
- Projection Distance Tele: 0.6 m ( 100 inch screen
- Projection Lens F Number: 1.6
- Projection Lens Focal Length: 3.7 mm
- Projection Lens Focus: Manual
- Offset: 6 : 1
Connectivity:
- USB Display Function: 3 in 1: Image / Mouse / Sound
- Interfaces: USB 2.0-A, USB 2.0, RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11b/g/n (optional), VGA in (2x), VGA out, HDMI in (3x), Composite in, RGB in (2x), RGB out, MHL, Jack plug out, Jack plug in (3x), Microphone input, Sync. in, Sync. out
- Epson iProjection App: Ad-Hoc / Infrastructure
Advanced Features:
- Security: Kensington lock, Control panel lock, Password lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection
- 2D Colour Modes: Dynamic, Cinema, Presentation, sRGB, Blackboard
- Other features: AV Mute Slide, Auto brightness adjustment, Automatic input selection, Built-in speaker, CEC compatible, Customizable user logo, Digital zoom, Direct Power on/off, Document Camera Compatible, Dual Pen Support, Dynamic lamp control, Easy OSD pre-setting, Home Screen, Interactive, Long lamp life, MHL audio/video interface, Microphone input, Multi-screen interactivity, PC Interactive, Split-Screen-Function
- Interactivity: Yes – pen and finger-touch
- Video Color Modes: Blackboard, Cinema, Dynamic, Presentation, sRGB
- Projector control: via: AMX, Crestron, Control4
General:
- Power consumption: 354 Watt, 309 Watt (economy), 0.37 Watt (standby), On mode power consumption as defined in JBMS-84 301 Watt
- Supply Voltage: AC 100 V – 240 V, 50 Hz – 60 Hz
- Product dimensions: 367 x 400 x 149 mm (Width x Depth x Height)
- Product weight: 5.8 kg
- Noise Level: Normal: 35 dB (A) – Economy: 30 dB (A) – Eco2: 29 dB (A)
- Supported Temperature: Operation 5° C – 40° C, Storage -10° C – 60,000° C
- Supported Humidity: Operation 20% – 80%, Storage 10% – 90%
- Included Software: Easy Interactive Tools, EasyMP Multi PC Projection, Epson Projector Management
- Options: Air filter ELPAF38, Connection and control box, Document camera, External Speaker, Pen tip(Felt), Pen tip(Teflon), Wireless LAN unit
- Compatible Operating Systems: Linux, Mac OS 10.10.x, Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Ubuntu 14.10, Ubuntu 15.04, Ubuntu 15.10, Ubuntu 16.04 LTS, Windows 10, Windows 8, Windows 8.1
- Loudspeaker: 16 Watt
- Room Type / Application: Meeting room / Classroom
- Positioning: Wall Mounted
- Colour: White / Grey
